How Wide Bandgap Materials Like SiC and GaN are Transforming EV Powertrains?

Transportation electrification has increased the need to develop efficient power electronics, which has put wide bandgap (WBG) semiconductors of silicon carbide (SiC) and gallium nitride (GaN) as essential contributors to superior electric vehicle (EV) powertrain development. They can withstand higher voltages, temperatures, and switching frequencies, unlike traditional silicon (Si), which has a bandgap energy of 1.1 eV and operates at 3.2 eV (SiC) and 3.4 eV (GaN). These properties help solve long-term problems with EVs, such as energy loss, thermal control, and system compactness, to create the best performance and range.

Look at the automotive semiconductor market report for market dynamics and more insights.

Better Power Conversion Efficacy

Direct current in EV powertrains is converted to alternating current to drive motors by inverters, which traditionally have conducted and switching losses of 5-10% in silicon IGBTs. SiC MOSFETs and GaN HEMTs make these less than 1 percent and efficiencies up to and above 99 percent. WBG materials have high electron mobility, which allows much faster switching, which is up to 100 kHz, compared to silicon (10-20 kHz), which reduces inductance loss and allows the use of smaller passive devices, such as inductors and capacitors. This increases to 5-15 percent gains in driving range, which is paramount to consumer adoption.

Increased Thermal and Power Density

WBG devices can be used with junction temperatures of up to 200 C, as opposed to the 150 C limit of silicon, eliminating the need for large cooling systems. In Tesla, the Model 3 inverter uses SiC modules, in which the cooling is reduced by half, and power density increases to 50 kW/L, more than 2x silicon. Low on-resistance (Rds(on)) in GaN further reduces inverter footprints by 30-40%, permitting compact designs in high-performance EVs such as those offered by Porsche or Lucid. These developments cut down the system costs in the long run, with smaller components saving on the bill of materials.

Driving implications on Charging and Drivetrains

WBG integration is also provided to onboard chargers (OBCs) and DC-DC converters. GaN allows 800 V designs, including ultra-fast charging at 350 kW, which shortens the times of sessions to 15 minutes. SiC has been used to improve traction inverters in motors above 500 kW to improve acceleration and hill-climbing torque. Players such as Wolfspeed and Infineon in the industry declare a 20-30 percent cut in total powertrain loss, which is more than the 20 million-plus EV sales in the world annually.

Issues still exist, such as increased initial costs (2-3x silicon) and supply chain maturity. But, through economies of scale, the U.S. CHIPS Act subsidies and Asian fabrication booms are eliminating the disparity. By the year 2030, the penetration of WBG shall be over 70 percent with regard to EVs, and this is bound to bring about a paradigm shift.

Finally, SiC and GaN are not the upgrades, but the basis of the next-generation EV powertrain; they are efficient, densely, and reliable and represent a completely new definition of automotive engineering.

FAQs

• What are wide bandgap materials?
  • Semiconductors SiC and GaN with bandgaps of 3.2-3.4 eV, allowing high voltage, high temperature operation not possible with silicon.
• What are the ways SiC/GaN are used to enhance EV efficiency?
  • They attain >99% inverter performance through low-loss switching, and add a 5-15% range and less thermal management requirements.
• How expensive or costly is the adopter of WBG?
  • Early 2-3x premium over silicon, which will be compensated by smaller systems and scale, aiming to achieve parity by 2028.
• What are EVs powered by SiC /GaN?
  • Tesla Model 3/Y (SiC inverters), Hyundai Ioniq 5 (SiC) and upcoming 800 V systems of Porsche Taycan and Lucid Air.
